The Original Resinator XL Base Model

Choose the Process You Need Today and Expand Tomorrow

TCI Scientific Innovations LLC is proud to offer The Original Resinator XL Base Model—a modular, high-capacity processing platform for commercial cultivators and extraction professionals who want to invest in one primary workflow without purchasing accessories they may not currently need.

Choose from three purpose-built configurations:

• XL Cryo-Trim® Edition
• XL Cryo-Sieve® Edition
• XL Ice-Water Wash Edition

Each edition includes the Resinator XL machine and the screen, tools, and operating accessories required for its designated application. Additional drum screens and accessory kits can be added later, allowing the system to expand as production demands change.

The XL Base Model uses the same commercial-grade platform found in the complete Resinator XL bundles. Its modular design gives high-volume operators a cost-conscious entry point into automated trimming, resin separation, or ice-water processing while preserving a clear path toward a more versatile system.

Choose Your XL Configuration

XL Cryo-Trim® Edition

Designed for rapid, bladeless trimming with CO₂-assisted flash-freezing.

Included:

• One 1/4-inch mesh trimming screen
• Thermometer
• Stopwatch
• CO₂ hose with fittings
• Food-grade leaf collection tool
• Cleaning brush

XL Cryo-Sieve® Edition

Configured for cold mechanical trichome separation and high-capacity kief collection.

Included:

• One 200-micron drum screen
• Three agitation balls
• Thermometer
• Stopwatch
• CO₂ hose with fittings
• Kief scraper
• Cleaning brush

XL Ice-Water Wash Edition

Configured for automated ice-water agitation and mechanical trichome separation.

Included:

• One 200-micron drum screen
• Thermometer
• Stopwatch

Key Features

Cryo-Trim® Processing

The Cryo-Trim® Edition combines bladeless tumbling with liquid CO₂ to flash-freeze unwanted leaf material before separation. Under suitable operating conditions, the system supports manufacturer-rated peak processing of up to 7 pounds per minute.

High-Volume Production

The Resinator XL Base Model is engineered for commercial throughput. Manufacturer-rated maximum daily production reaches up to 2,016 pounds of wet material or 672 pounds of dry material for trimming and sifting applications.

Cryo-Sieve® Separation

The Cryo-Sieve® Edition mechanically separates trichomes from properly prepared biomass at subzero temperatures. Process up to 15 pounds of trim per run for efficient kief and resin collection.

Ice-Water Hash Processing

The Ice-Water Wash Edition automates the agitation stage of bubble hash production, reducing the manual labor associated with conventional washing while supporting repeatable batch processing.

Liquid CO₂ Compatibility

The Cryo-Trim® and Cryo-Sieve® configurations are designed to integrate with a compatible liquid CO₂ supply for flash-freezing and subzero separation.

Modular Expansion

Begin with one processing method and add compatible screens, drums, and accessory kits when additional capabilities are required. There is no need to replace the core machine as the operation grows.

Industrial Motor

A quiet, UL-rated industrial motor provides the power and reliability required for routine commercial use.

Simplified Cleaning

Removable screens and accessible food-contact components make routine cleaning and transitions between batches more manageable.

Manufacturer-Rated Capacities

Application	Maximum Rated Capacity
Wet-material trimming or sifting	Up to 2,016 lbs daily
Dry-material trimming or sifting	Up to 672 lbs daily
Wet-material ice-water washing	Up to 672 lbs daily
Dry-material ice-water washing	Up to 224 lbs daily
Typical batch capacity	Approximately 14 lbs per cycle
Cryo-Sieve® separation	Up to 15 lbs per run
Cryo-Trim® peak processing rate	Up to 7 lbs per minute

Actual throughput will vary based on material type, moisture content, preparation, selected screen, cycle duration, operating schedule, and facility workflow.

Specifications

Specification	Details
Motor	UL-rated industrial motor
Available editions	Cryo-Trim®, Cryo-Sieve®, or Ice-Water Wash
Liquid CO₂ compatibility	Cryo-Trim® and Cryo-Sieve® configurations
Screen design	Removable and interchangeable
Expansion options	Compatible drum screens and accessory kits
Primary applications	Bladeless trimming, cold sifting, and ice-water washing
Warranty	Two-year structural and electronic coverage; one-year wear-component coverage

Warranty Coverage

Structural components, structural hardware, and electronics are covered by a two-year manufacturer’s equipment warranty against defects in materials or workmanship.

Consumable and wear components—including rubber gaskets, draw latches, connection hardware, and clear plastic lids—are covered for one year. Warranty eligibility, exclusions, and service procedures are subject to the manufacturer’s complete warranty terms.

All sales are final.

Commercial Capacity Without Unnecessary Accessories

The Original Resinator XL Base Model gives commercial operators the freedom to build around their immediate production needs. Select the appropriate edition for trimming, cold separation, or ice-water washing, then expand the system with additional Resinator components as the operation develops.

Available from authorized reseller TCI Scientific Innovations LLC at www.TCIScientific.com .
